Explosion proof Irled/Light

Explosion Proof Fill-in Light.B

Model:FNKZ-IC.B

weight:3KG

Colour:primary color of stainless steel/paint colors
Online order

Main features:

·CNEx certificated

·Stainless steel 304/316L

·Surface finish: electropolished or corrosion resistant paint finish

·IP68

·1 cable gland

·Applicable for the extreme circumstances with explosive gas or dust, like petro-chemical, offshore, marine, oil tank, gas station, onshore sites.

General Specification
Model	FNKZ-IC.B
Explosion levels	Ex d ⅡC T6 Gb/Ex tD A21 IP68 T80℃ IP68(CNEX) II 2 G Ex db IC T6 Gb/II 2 D Ex tb IIIC T80℃ Db(ATEX)
Waterproof	IP68
Material	Stainless steel 304/316L
Surface Polishment	Electro-polished
Window	Borosilicate, both side nano coating
Voltage	DC12V
Current	≤2A
Power Consumption	≤8W
Operation Temperature	-20℃～+60℃
Operation Humidity	≤90%RH
Dimension	210mm(L)×140mm(W)×150mm(H)
Weight	3kg
Packing	Carton box with EPE inside
Packing size	450mm(L)×190mm(W)×190mm(H)
