型号:FNKZ-IC.R
重量:8KG
颜色:primary color of stainless steel/paint colors
Main features:
· CNEx certificated, IP68
· Stainless steel 304/316L
· Surface finish: electropolished or corrosion resistant paint finish
· Built-in video compression coding, easy for network transmission powerful IDE image detail enhancement algorithm
· Intelligent high-temperature pre-alarming with various adjustable grades, higher detection efficiency, less misinformation
· Embedded intelligent analysis supports motion detection, line crossing detection, regional entry/exit detection, and intelligent PTZ tracking
· Professional photoelectric zooming technology
· AGC(automatic gain stability), 3D noise reduction, IDE (image details enhancement algorithm)
· Double serial communication: RS-232*1, R-485*1
· Application Scenario: It is mainly applicable in scenarios of zero visibility and strong light source interference, such as airport, harbor, tourism area, perimeter, oilfield, military, key fields
Item | 384×288 | 640×480 |
Detector Data | ||
Material | aSi | |
IR resolution | 384×288 | 640×480 |
Pixel pitch | 17μm | |
Spectral range | 7.5~14μm | |
NETD/Sensitivity | ≤70mK | ≤60mK |
Lens Data | ||
Lens(optional) | 35mm、50mm、75mm athermal lens, 100mm、150mm motorized lens, 25~100mm、30~150mm、25~225mm continuous zoom lens、60/150mm dual FOV lens(other lens are optional) | |
Image Performance | ||
Image enhancement | IVE image enhancement algorithm | |
Frequency | 50Hz | |
Amplification | 2X, 4X | |
Polarity/LUT mode | Black hot/White hot | |
Startup time | 3s | |
Image gain | Auto/Manual | |
Focusing | Motor | |
Cross cursor | ON/OFF | |
Image frozen | Yes | |
Interface | ||
Primary electrical connector | 40pin | |
Control | RS232 | |
Analog video output | PAL | |
Digital video output | Cameralink、LVCMOS optional | |
Keypad | 4 button keyboard | |
Power System | ||
Working voltage | DC: +4V~+5.5V(Standard: 5V) | |
Power consumption | 1.5W | 1.25W |
Reverse polarity protection | Yes | |
Over&Under voltage protection | Yes | |
