Thermal Camera

Explosion Proof Thermal PTZ Camera.STH

Model:FNKZ-PTZ.STH

weight:33KG/35KG

Colour:primary color of stainless steel/paint colors
Online order

Product overview
UNV
dahua
others

Main features:

· CNEx certificated, IP68

· Stainless steel 304/316L

· Surface finish: electropolished or corrosion resistant paint finish

· Built-in video compression coding, easy for network transmission powerful IDE image detail enhancement algorithm

· Intelligent high-temperature pre-alarming with various adjustable grades, higher detection efficiency, less misinformation

· Embedded intelligent analysis supports motion detection, line crossing detection, regional entry/exit detection, and intelligent PTZ tracking

· Professional photoelectric zooming technology

· AGC(automatic gain stability), 3D noise reduction, IDE (image details enhancement algorithm)

· Double serial communication: RS-232*1, R-485*1

· Application Scenario: It is mainly applicable in scenarios of zero visibility and strong light source interference, such as airport, harbor, tourism area, perimeter, oilfield, military, key fields

General Specifications
Model	FNKZ-PTZ.STH
Explosion level	ExdⅡCT6 Gb/Ex tD A21 IP68 T80℃
Input Voltage	AC220V±10%
Protection level	IP68 Standard, Surge Protection and Voltage Transient Protection
Material	SUS304/316L
Working Temperature/Humidity	-20℃～+60℃, ≤90%RH
Pan Range	360° continuous
Tilt Range	-90°~+90°
Pan speed	Configurable, from 0.1°/S~300°/S
Tilt speed	Configurable, from 0.1°/S~240°/S
Number of Preset	256
Power-off Memory	Support
Park Action	Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan//Frame Scan/Panorama Scan
PTZ Position Display	ON/OFF
Power Supply	220VAC
Power Consumption	Max:40w
Dimension	420mm(L)×238mm(W)×378mm(H)
Weight	35kg
Packing	Carton box with EPE inside（605mm500mm305mm）
